Medium Duty Racking
What is Medium-Duty Racking?
Medium-duty racking (also called medium-duty steel racking) refers to industrial shelving designed to store goods with a load capacity ranging from 200kg to 500kg per level.
This type of warehouse racking suits various facilities, from component and parts warehouses, mini-marts, to medium-scale manufacturing facilities.
Unlike light-duty and heavy-duty warehouse racking, medium-duty systems balance load-bearing capacity, investment costs, and operational flexibility. These systems represent an ideal choice for warehouses that don’t utilize pallets or have small to medium floor space.
Medium-Duty Racking Classification at Vinatech Group
Currently, Vinatech classifies medium-duty racking based on frame construction:
- Bolted cross-braced medium-duty racking: Compact design, easy to disassemble when relocation is needed. Standard blue-orange colors, diverse size options.
- Welded fixed cross-braced medium-duty racking: Welded frame for enhanced stability, high structural integrity. Standard black color, multiple size selections.
Basic Technical Specifications for Medium-Duty Steel Racking
The medium-duty steel racking line manufactured by Vinatech Group features the following basic specifications:
- Type: Industrial steel racking
- Dimensions (L x W x H): 1500 x 600 x 2000mm | 2000 x 600 x 2000mm
- Load capacity: 200 – 500 kg/tier
- Number of tiers: 3 – 7 tiers (customizable upon request)
- Material: SPCC steel conforming to SPCC JIS G3141 standard
- Surface treatment: Powder coating
- Standard colors: Blue-orange or black
Medium-Duty Warehouse Racking Structure
Medium-load warehouse racking (medium-duty racking) features simple yet robust construction, easily customizable and suitable for various medium-weight goods. A standard medium-duty racking unit at Vinatech Group typically includes:
- Omega uprights (rack columns): Main load-bearing frame, made from 1.5-2mm thick cold-rolled steel, with periodic holes punched 50mm apart for beam installation.
- Beam supports (tier supports): Connected to uprights via hook pins or safety pins, with flexible lengths from 1.2m to 2.4m.
- Decking/tier panels: Options include powder-coated sheet metal, moisture-resistant MDF boards, or welded wire mesh depending on usage requirements and warehouse environment.
- Horizontal and diagonal bracing: Made from flat steel, increases frame stability, installed on the back or sides to prevent vibration.
Common Medium-Duty Warehouse Racking Dimensions
Popular medium-duty racking models currently available range from 2 to 6 tiers, with size selection based on warehouse floor area and stored goods type.
3-Tier Medium-Duty Racking
Construction specifications for 3-tier medium-duty racking at Vinatech Group:
- Height: 1200mm
- Length: 1200mm
- Width: 450mm
- Load capacity: >200kg/tier
- Coating: Anti-rust powder coating
- Structure: Hook-clip assembly
- Color: Blue-orange
- Decking: Board, cement board, mesh, or edge-rolled sheet metal
Projects featuring 3-tier Vinatech medium-duty racking installed
4-Tier Medium-Duty Steel Racking
- Height: 1600mm
- Length: 1800mm
- Width: 550mm
- Load capacity: >400kg/tier
- Coating: Anti-rust powder coating
- Frame columns: Omega 50x60mm
- Color: Blue-orange
- Decking: Board, cement board, mesh, or edge-rolled sheet metal
4-tier medium-duty steel racking installation project at Vinatech Group
- Black medium-duty steel racking
- White medium-duty steel racking
- Green medium-duty steel racking
5-Tier Medium-Duty Warehouse Racking
Characteristics of the 5-tier medium-duty warehouse racking we manufacture:
- Height: 2000mm
- Length: 2400mm
- Width: 650mm
- Load capacity: >600kg/tier
- Modern technology design, fully powder-coated for oxidation resistance
- Omega-shaped frame columns 50x60mm create solid rack structure
- Color: Blue-orange
- Decking: Tier surfaces can utilize edge-rolled steel sheets, laminated boards, mesh, etc.
Vinatech 5-tier medium-duty racking project
- 4-tier medium-duty warehouse racking
- 5-tier medium-duty warehouse racking
6-Tier Medium-Weight Racking
6-tier medium-duty warehouse racking suits small to medium warehouses storing not excessively heavy items, optimizing both cost and functional usage.
Characteristics of this 6-tier medium-duty racking model:
- Height: 2200mm
- Length: 1600mm
- Width: 600mm
- Tier panels: 6
- Color: Blue, orange
- Load capacity: >350kg/tier
- Warranty: 2 years
- Brand: Vinatech Group
Vinatech 6-tier medium-duty racking project (Custom design)
Explore more medium-load warehouse racking lines manufactured at Vinatech Group at factory-direct prices:
V-slot perforated steel racking: display racks, advertising racks, grocery store racks, etc.
Non-Standard Medium-Duty Warehouse Racking
Non-standard medium-duty storage racking is custom-designed according to each warehouse’s actual needs, with load capacities from 200-800kg/tier. Dimensions, tier numbers, and decking types (sheet metal, mesh, etc.) can be customized.
Advantages:
- Flexible design, suits warehouse specifications
- Powder-coated steel frame, durable and easy to install
- Optimizes floor space, enhances storage efficiency
REFER TO DETAILED TECHNICAL SPECIFICATIONS FOR MEDIUM-DUTY RACKING
Outstanding Advantages of Medium-Duty Racking
Medium-duty racking is optimally designed for medium-weight goods, combining excellent load-bearing capacity, flexibility, and reasonable cost.
Excellent Load Capacity – Suits Various Goods Types
- Robust rack frame, high load-bearing beams
- Ensures long-term stability, no sagging or tier sinking
Flexibility – Easy to Modify & Expand
- Adjust tier height in minutes
- Can add connecting bays or quickly disassemble when changing warehouse layout
Simple Installation
- No bolts or screws required for rapid installation
- Convenient inspection, maintenance, individual component replacement
Reasonable Investment Cost
- Lower price than heavy-duty or automated racking
- Average lifespan 8-12 years, saves operational and replacement costs
High Durability & Aesthetics
- Cold-rolled steel, premium powder coating resists rust and scratches
- Maintains color durability, color customization by brand or storage area
Applications of Medium-Duty Racking
Vinatech Group has implemented hundreds of medium-duty racking projects across multiple industries, evaluating medium-duty racking with the notable advantage of flexible and effective use for various warehouses:
- Automotive and motorcycle parts warehouses
- Electronic components, light industrial warehouses
- File and document storage (offices, schools)
- Mini-marts, convenience stores
- E-commerce warehouses
Additionally, medium-duty racking for cold storage and cool storage is increasingly popular because:
- Powder coating resists moisture
- Mesh-style rack surfaces allow air circulation, suitable for storing dried foods, pharmaceuticals
Medium-Duty Racking Installation Projects at Vinatech Group
Latest 2025 Medium-Duty Racking Price List
In 2025, medium-duty racking prices remain relatively stable despite fluctuations in material and steel prices.
Vinatech Group is a direct manufacturing and construction unit, ensuring competitive pricing and custom design. Contact us for detailed quotes and free drawings.
Reference price list for medium-duty racking (updated 2025):
| Racking Type | Dimensions (LxWxH) | Load/Tier | Tiers | Unit Price (VND/set) |
|---|---|---|---|---|
| 3-tier MDF deck medium warehouse racking | 2000 x 600 x 2000 mm | 300 kg | 3 | 1,450,000 – 1,650,000 |
| 3-tier welded wire mesh medium warehouse racking | 1500 x 500 x 2000 mm | 400 kg | 3 | 1,700,000 – 1,900,000 |
| Hook-clip assembly medium warehouse racking (connector unit) | 1800 x 600 x 2200 mm | 300–400 kg | 3–4 | 1,300,000 – 1,500,000 |
| 3-tier perforated steel deck medium warehouse racking | 1500 x 600 x 2000 mm | 400 kg | 3 | 1,800,000 – 2,000,000 |
| 4-tier Melamine-coated MDF medium warehouse racking | 1800 x 600 x 2400 mm | 350 kg | 4 | 1,900,000 – 2,200,000 |
| 4-tier thick sheet metal medium warehouse racking | 2000 x 600 x 2500 mm | 500 kg | 4 | 2,000,000 – 2,350,000 |
| 4-tier powder-coated flat steel deck medium warehouse racking | 2000 x 700 x 2500 mm | 450 kg | 4 | 2,300,000 – 2,600,000 |
| 5-tier MDF deck medium warehouse racking | 2000 x 600 x 3000 mm | 300 kg | 5 | 2,200,000 – 2,500,000 |
| 5-tier thick sheet metal medium warehouse racking | 2000 x 600 x 3200 mm | 500 kg | 5 | 2,700,000 – 3,000,000 |
| 5-tier welded wire mesh medium warehouse racking | 1500 x 500 x 3000 mm | 400 kg | 5 | 2,400,000 – 2,600,000 |
| 5-tier hook-clip assembly medium warehouse racking | 1800 x 600 x 3000 mm | 300–400 kg | 5 | 2,000,000 – 2,300,000 |
| 6-tier MDF deck medium warehouse racking | 2000 x 600 x 3600 mm | 300 kg | 6 | 2,600,000 – 2,900,000 |
| 6-tier thick sheet metal medium warehouse racking | 2000 x 600 x 3800 mm | 500 kg | 6 | 3,200,000 – 3,500,000 |
| 6-tier welded wire mesh medium warehouse racking | 1500 x 500 x 3600 mm | 400 kg | 6 | 2,800,000 – 3,100,000 |
| 6-tier hook-clip assembly medium warehouse racking | 1800 x 600 x 3600 mm | 300–400 kg | 6 | 2,400,000 – 2,700,000 |
| 4-tier mobile medium warehouse racking with casters | TBD | TBD | TBD | TBD |
| Non-standard medium warehouse racking | TBD | TBD | TBD | TBD |
Vinatech Group – Vietnam’s Leading Trusted Warehouse Racking Manufacturer
For orders of 200 million VND or more, Vinatech Group will manufacture custom medium-duty racking
✅ Warehouse racking products manufactured to international standards | ⭐️ISO 9001:2015, ISO 14001:2015, ISO 45001:2015, AS 4084-2023
✅ Using POSCO steel | ⭐️Grade I cold-rolled steel meeting standards, ensuring durability and strength
✅ Strict quality inspection process | ⭐️Inspecting welds, thickness, paint layers, and load testing before factory departure
✅ Warranty period | ⭐️From 1-5 years depending on product line (Including inspection, repairs, damaged components, and racking system upgrades)
✅ Free surveying and consultation | ⭐️Design and consultation support policy ⭐️On-site warehouse surveying ⭐️2D, 3D design
Why Choose Medium-Duty Steel Warehouse Racking at Vinatech Group?
With 14 years of experience, Vinatech Group has directly constructed and supervised numerous medium-duty warehouse racking installation projects for factories, enterprises, and large distribution systems. Vinatech Group’s advantages:
✅ High-quality products, standard load capacity: Vinatech medium-duty warehouse racking is manufactured from cold-rolled steel, anti-rust powder coating, with standard thickness (1.5mm-2.0mm), ensuring stable load-bearing capacity, accurate to design specifications from 200-500kg/tier.
✅ Modern manufacturing technology – High precision: Closed automated production line meeting ISO 9001:2015 standards ensures uniform and solid racking, guaranteeing quick assembly without deviations, saving construction time.
✅ Customization per customer requirements: Vinatech Group accepts custom medium-duty warehouse racking orders for orders >200 million: custom dimensions, tier numbers, paint colors, decking types (sheet metal, MDF, mesh, steel boards, etc.), helping optimize actual warehouse space.
✅ Competitive pricing – Good warranty policy: Compared to many imported brands or other intermediaries, Vinatech Group’s 2025 medium-duty assembly racking price list is reasonable, especially for large orders and corporate customers.
✅ Specialized consulting and technical team: From on-site surveying, layout consultation, to installation construction – Vinatech Group provides comprehensive warehouse racking solutions, ensuring schedule and operational safety.
✅ Two modern factories in the North and South, total area of 50,000 m², ensuring large-scale production capacity.
✅ Extensive distribution network, over 200 dealers nationwide. Team of 500 experienced personnel, always ready for professional consulting, installation, and warranty services.
✅ Over 50,000+ successful warehouse design projects, serving diverse industries and business models.
Choosing and properly installing medium-duty racking not only increases equipment lifespan but also ensures safety, efficiency, and long-term cost savings. If your enterprise isn’t certain which configuration suits your needs, contact Vinatech Group’s technical team – we’re ready to consult and design free warehouse layouts via hotline 086.758.999.
